Microprocessor Training Kit With LCD Display

Product Description

• Based on 8085 CPU operating at 6.144 MHz crystal.
• 16K bytes of EPROM with powerful monitor program.
• 8K byte of RAM available to the user.
• Battery backup for user's RAM with 3.6V rechargeable cell
• Total on board memory expansion upto 64K bytes using 2732/2764/27128/6264.
• Memory mapping definable by the user.
• 20x2 Liquid Crystal Display (LCD).
• 104/105KeysIBM PC Compatible ASCII Keyboard
• 48 programmable I/O lines provided through 2 nos. of 8255.
• 16 bit programmable timer/counter using 8253.
• RS-232C interface for CRT using SID / SOD lines.
• Two modes of Commands: - Key board Mode & Serial Mode
• All address, data and control lines are buffered and made available at the edge connector as per STD Bus configuration.
• Powerful Software Commands like relocate, string, fill, insert, delete, block move, memory compare etc.
• On board Single Line Assembler/Disassembler.
• Facility for Downloading/Uploading files from/to PC.
• In-built Power Supply :
