Microprocessor Training Kit With Eprom Programmer

Product Description

• Based on 8085 CPU operating at 6.144 MHz crystal frequency.
• 8/16K bytes of EPROM loaded with powerful monitor program.
• 8/16K bytes of RAM available to user.
• Battery Backup for RAM with 3.6V rechargeable cell.
• Total on board memory expansion upto 64K bytes using 2732/2764/27128/6264/ 62256 with total 4 sockets of 28 pin.
• Memory mapping definablebythe user.
• 16 bit programmable TIMER/COUNTER using 8253
• 48 programmable I/O lines provided through 2 nos.of 8255
• RS-232C interface for CRT Terminal with auto baud rate.
• EPROM Programmer for 27 series using 28 pin ZIF socket with facility to Program, Verify, List & Blank Check.
• Two modes of commands: Hex Key pad mode & Serial mode
• All address, data & control lines are buffered and made available at the edge connector as per STD bus configuration.
• 25/28 key hexadecimal keyboard and six seven segment display through 8279.
• Powerful software commands like Relocate, String, Fill, Insert, Delete, Block Move, Examine & Compare Memory, Examine Register, Insert Data, Delete Data, Single Step, GO, Break Point in both Serial and Keyboard mode.
• On Line Single Line Assembler/Disassembler.
• Facility for Downloading/Uploading files from/to PC.
• In-built Power supply
