Microprocessor Training Kit With Inbuilt Power Supply

Product Description

• Based on 8085 CPU operating at 6.144 MHz crystal frequency
• 8K bytes of EPROM loaded with powerful monitor program
• Total on board memory expansion upto 64K bytes using 2732/2764/27128/6264/ 62256 with 1 socket of 28 pin.
• Battery back up for RAM with 3.6V rechangeable cell.
• Memory mapping definable by the user.
• 16 bit programmable TIMER/COUNTER using 8253.
• 24 I/O lines provided through 8255
• 22 I/O lines provided through 8155
• RS-232C interface through SID/SOD Lines with Auto baud rate.
• Two modes of commands: - Hex Key pad mode & - Serial mode All address, data & control lines are buffered and made available at the edge connector as per STD bus configuration.
• 25/28 key hexadecimal keyboard and six seven segment displays through 8279
• Powerful software commands like Relocate, String, Fill, Insert, Delete, Block Move, Examine/Compare Memory, Examine Register, Insert Data, Delete Data, Single Step, GO, Break Point in both Serial & Keyboard mode.
• Facility for Downloading/Uploading files from/to PC.
• In-Built power supply:+5V/1.2A
