Microprocessor Trainer Kit (LED)

Biotek Engineers is manufactures,exporter & suppliers Microprocessor Trainer Kit (LED)

•  8086/8088 CPU operating at 2.5/5MHz
•  8086 Processor can be replaced by 8088 Processor
•  On-board sockets provided to facilitate the use of 8087 Coprocessorand 8089 I/O Processor
•  16K bytes of RAM using two nos. of 6264 with Battery Backup expandable up to 256KB
•  16K bytes of powerful monitor EPROM using two nos. of 27512
•  72 I/O lines through 3 nos. of 8255 brought at 26 Pins FRC Connector to  interface with IC-XX Series
•  16 bit Timer/Counter through 8253 brought out at 20 Pins FRC Connector
•  RS-232C interface using 8251 brought out at 9 Pins DType Connector. On-board Interrupt controller using 8259 brought out at 20   Pins FRC Connector
•  28 keys hexadecimal keyboard and eight seven segment display using 8279

Two modes of operation:

• Keyboard Mode
• Serial Mode

• Powerful Commands like Examine/Edit Memory, Examine/Edit Register, Single stepping, Execution, Block Move can be used through hex keyboard or PC serial mode
• Facility for Downloading/Uploading files from/to PC
• All address, data & control lines are available on KXT Bus 50 pin FRC Connector to interface with SC-XX Series
• All ICS are mounted on IC Sockets.
• Bare board Tested Glass Epoxy SMOBC PCB is used
• In-Built Power Supply of +5V/2A, ±12V/250mA
• Attractive Wooden enclosures of Light weight Australian Pine Wood

Optional
PRINTER INTERFACE to interface with DOT MATRIX Printer
