WOODWORKING LATHES

• Max. distance between centers                              1200mm
• Height of centers over bed                                     120mm
• Max. copying diameter                                          150 mm
• Max. diameter permitted by traveling steady        90 mm
• Connection for driving and tailstock centre          CM 3
• Saddle feed speed                                                  0 ÷5 meter /min
• Saddle return speed                                               5 meter/min
• Spindle motor                                                        2,9KW
• Variable Spindle speeds R.P.M.                            (900 - 1500 - 2200 – 3000)
• Motor power of hydraulic unit                              0,75 KW
• Installed power                                                      3,75KW
• Operating pressure                                                 25 ÷ 30 bar
•  Oil tank                                                                 20Liter
• Overall dimensions:                                               Length x Height x Width 2400 x 650 x 1540mm
• Sound pressure level at operator position              71 db

The machine includes:

• Work- piece centering device that Permits the rapid centering of work-pieces.
• Tool support rest for occasional hand turning finishes.
• Traveling steady rest (max. Ø 90 mm) with pre-cutting tool that has interchangeable knife inserts.
• For mass production runs a metal template should be used.
• A wooden sample can also be utilized for small batches.
• Copying saddle assembly with 2 dust extractions.
• Electrical control panel with hydraulic saddle speed regulator.
• Drive centre with 2 interchangeable heads 28 and 45 mm Ø
• Tailstock revolving centre 12 mm Ø
• Traveling steady rest max. Ø 90 mm (square 65 x 65 mm) with reduction bush
• 2 vertical gouges, radius 1,2 mm and 1 pre cutting tool, Motor protection switch, Emergency push-button, Front sliding
• guard, Service tools in toolbox
• Abrasive stone for cutting edge dressing.
