TRI AXIAL TEST SET

• Triaxial cell for specimens up to 70 mm diameter.
• Pedestal for 70 mm specimens.
• Top cap with drainage for specimens of 70 mm.
• Base plate, in aluminum for specimens of 70 mm.
• Porous disc for 70 mm specimens (set of 2).
• Suction sleeve stretcher for 70 mm - 2.8" - 3" specimens.
• Membrane, rubber latex for 70 mm - 2.8" specimens (30 pieces).
• O-ring neoprene for 70 mm - 2.8" specimens (30 pieces).
• Filter drain for 70 mm specimens pack of 50.
• Two part split mould for 70 mm specimens.

SAMPLE PREPARATION:

• Sampler for 70 mm samples piston and tube included.
• Rack and pinion sample extruder bench model.
• Allows the insertion of sampling tubes into a soil sample.
• with a rack and pinion mechanism with minimal disturbance; it is then used to extrude the resultant sample from the sampling tube.
• Max. Clearance between platens: 435 mm.
• Min. Clearance between platens: 0 mm.                                                                                                                ELECTRIC AUTOMATIC LATHE:
• Used to turn the sample then a cutting disc can move horizontally & vertically so that to trim the sample to the required diameter.
• Variable speed control.
• Max sample diameter 106 mm..
• Max vertical movement of cutting disc 220 mm.
• Turning speed 0-100 rpm.
• Complete with a pair of 38.1 mm dia. Platens.
• Power: 220 v - 50 hz - 1 ph.
• Extra Platens: diam. 70 mm (2 pcs).

• Digital gauge 10 bar; battery operated.
• De-airing block for pressure transducer.

• Volume change measurement device.
• Made of bronze with a measurement capacity of 100cc.
• Supplied with 2 rolling membranes.
• Max working pressure 1000Kpa.
• Supplied with dial gauge: precision 0.01 mm 30 mm travel.

• Bladder air-water cylinder.
• (10 bar) with valve and connectors.
• Max working pressure 1000Kpa.
• Max input air pressure 1700Kpa.
• Regulation range 0-1000 Kpa • Cylinder capacity 3500cc.
