Flow through Particle Layers

Product Description

• Investigation of the properties of fixed and fluidised beds subjected to liquid flow
• Glass test tank with sintered filter medium on its base
• Test tank removable for filling
• Downward flow to investigate fixed beds
• Upward flow to investigate fluidised beds
• Flow meter with valve for adjustment
• 2 manometers with differing measuring ranges to measure pressure loss through the test tank
• Steel rule to measure the height of the fixed or fluidised bed

 Test tanks
- length: 510mm
- inside diameter: approx. 37mm
- material: DURAN glass

Filter medium
- thickness: 2mm
- material: sintered metal

Expansion tank
- capacity: approx. 4500mL
- material: PVC

Measuring ranges
- flow rate: 60...820mL/min
- tube manometers: 2x 0...500mmWC
- manometer: 0...250mbar
- steel rule: 10...500mm
