Depth Filtration

Biotek Engineers is manufactures,exporter & suppliers  Depth Filtration

  •  Depth filtration with sand filter
  •  Sand filter backwash possible
  •  20 tube manometers to measure the pressures in the filter bed
  •  Plotting of Micheau diagrams
  •  Raw water and backwash pump
  •  Electromagnetic flow rate sensor
  •  4 ball valves with electric drive
  •  Measurement of flow rate, differential pressure, system pressure and temperature
  •  Filter velocity adjustable
  •  Software with control functions and data acquisition via USB under Windows Vista or Windows 7

Sand filter
- Outer diameter: 200mm
- Inside diameter: 150mm
- Height: 1660mm

Raw water pump
- Max. flow rate: 13m³/h
- Max. head: 10m

Backwash pump
- Max. flow rate: 3m³/h
- Max. head: 37m

Tanks for raw water and treated water
- Capacity: each 180L


Measuring ranges
- Flow rate: 0...1300L/h
- Tube manometers: 20x 0...1500mmWC
- Differential pressure: -1...1bar
- System pressure: 0...4bar
- Temperature: 0...100°C
- Filter velocity: 0...70m/h
230V, 50/60Hz, 1 phase or 230V, 60Hz/CSA, 3 phases
Water connection, drainage
