Computerized Universal Testing Machine

Product Description

Computerized Universal Testing Machine

Biotek Engineers is manufacture, exporters & suppliers of: Computerized Universal Testing Machine

Specifications:

Control Unit :
Capacity : Available from 5 to 300 Ton.
Min Resolution: 1/10000.
Accuracy: ±1%.
Driving Method: Hydraulic System.
Ram Stroke(mm): from 100 to 250 depending upon machine capacity.
Effective Column Interval(mm): 300 to 750 depending upon machine capacity.
Crosshead Speed(mm/min): from 50 to 100 depending upon machine capacity.
Testing Speed(mm/min): from 50 to 250 depending upon machine capacity.
Machine weight : 1500 to 4000kg depending upon machine capacity.
Power: 220/440V, 50HZ or as desired by customers.
Tension (mm): Max.Space:700, Grip for Rod: 10 ~ 70, Grip for Plate: 13~ 65x90.
Compression: Max.Space: 700, Compression Plate:160(Dia.)
Transverse & Bending (mm): Max.Space:810, Punch Tip:R22x140,Roller: 50(Dia.)x161.
Above three specifications shall depend upon machine capacity.
With one set of testing program software.
