Fatigue Testing Machine

Biotek Engineers is manufacture, exporters & suppliers of: Fatigue Testing Machine

This machine is used to test the fatigue strength of materials and to draw S-N diagram by research institute, laboratories, material manufacturers and various industries. This is rotating beam type machine in which load is applied in reversed bending fashion. The standard 8 mm dia specimen is held in special holders at its ends and located such that it experiences a uniform bending moment. The specimen is rotated at 4200 rpm by a motor. A complete cycle of reversed stresses in all fibres of the specimen is produced during each revolution. The bending moment is applied with the lever system and can be easily changed by moving a weight over the lever.

Salient Features

    Max. bending moment (Kg. cm)-200
    Bending moment adjustable(Kg.cm) -25 - 200
    Ranges : 1 - Kg.cm II -Kg.cm
    25- 125 125-200
    Gripping dia of specimen(mm)-12
    Testing dia of specimen(mm)-8
    Rotating speed in RPM -4200
    Accuracy of applied bending moment - ±1%
    Mechanical Counter:No. of digits Multiplying factor - 63
    Power required in HP -0.5
    Main Supply -3ph 440v 50hz
    Overall size(mm)-1000LX500WX600H
    Weight (Kg)- 120
