Compression Testing Machine Hand Operated

Product Description

Compression Testing Machine Hand Operated

Biotek Engineers is manufacture, exporters & suppliers of: Compression Testing Machine Hand Operated

For Compression test on Concrete or similar materials. Suitable for use on Concrete Cubes of any size upto 5 cm x 5 cm x 5 cm, 7.06 x 7.06 cm, 10 cm x 10 cm x 10 cm, and 15 cm x 15 cm x 15 cm also on 10 x 20 cm and 15 x 30 cm high Concrete Cylinders. The load is applied thru hydraulic assembly. The lower platen is on the Hydraulic ram, and upper having a spherical seating is adjustable. The machine is provided with an air release valve and the load is automatically indicated on the 15 cm dia hydraulic pressure calibrated against  Proving Ring and fitted with a legless max pointer in addition to the live pointer.

Features:

High efficiency
Low maintenance
High performance

Specifications:

Compression Testing Machine, Hand Operated, 25,000 kg (250 KN, channel) Model: double plunger pump with hydraulic pressure gauge. Our own Calibration
Compression Testing Machine, Hand Operated, 50,000 kg (500 KN, channel) Model: double plunger pump with hydraulic pressure gauge 0-500 KN Our own Calibration.
Compression Testing Machine, Hand Operated, 100,000 kg (1000 KN, channel) Model: fitted with double plunger pump with hydraulic pressure gauge. 0-100 KN capacity. Our own Calibration.
