Compression Refrigeration System

Product Description

Compression Refrigeration System

Biotek Engineers is manufacture, exporters & suppliers of: Compression Refrigeration System

1] investigation of a refrigeration system with different expansion elements

[2] refrigeration circuit consisting of a hermetic compressor, condenser, evaporator and expansion element

[3] transparent finned tube heat exchangers as condenser and evaporator to observe the phase transitions of the refrigerant

[4] expansion valve and capillary tubes of different lengths as expansion elements

[5] receiver for underfilling/overfilling the system with refrigerant

[6] sensors record pressure and temperature

[7] compressor equipped with two pressure switches

Technical Data

Compressor

- power consumption: 213W at 7,2°/32°C

- refrigeration capacity: 372W at 7,2/32°C

Condenser and evaporator with fan

- max. volumetric air flow rate condenser: 300m³/h

- max. volumetric air flow rate evaporator: 180m³/h

Capillary tubes: 1,5m, 3m, 6m

Receiver for refrigerant: 1,3L

Measuring ranges

- pressure: -1...9bar / -1...24bar

- temperature: 4x -40...150°C, 1x -100...100°C

- flow rate: 2...18m³/h

- electric power consumption: 0...1000W
