Refrigeration Circuit with Variable Load

Product Description

Refrigeration Circuit with Variable Load

Biotek Engineers is manufacture, exporters & suppliers of: Refrigeration Circuit with Variable Load

[1] investigation of a refrigeration circuit with water circuit as load

[2] refrigeration circuit with compressor, condenser with fan, thermostatic expansion valve and coaxial coil heat exchanger as evaporator

[3] water circuit with pump, tank with heater as cooling load at the evaporator

[4] heater with controller to adjust the tank temperature

[5] record of all relevant measured values and display directly at the location of measurement

Technical Data

Compressor

- refrigeration capacity: approx. 380W at 5/40°C

Evaporator

- refrigerant volume: 0,4L

- water volume: 0,8L

Condenser

- transfer area: approx. 1,25m²

- fan power consumption: 4x 12W

Pump

- max. flow rate: 1,9m³/h

- max. head: 1,4m

Tank

- volume: approx. 4,5L

- heater: approx. 450W

Measuring ranges

- pressure: 2x -1...15bar

- compressor power: 1x 0...750W

- temperature: 6x 0...100°C

- flow rate (water): 1x 0,05...1,8L/min
