UNIVERSAL MILLING MACHINE

UNIVERSAL MILLING MACHINE

Specification:

•  Universal milling machine, type.
•  The frame and base are made of high quality cast iron strong.
•  Working table min. 1200x280 mm. With min. 3 T-slot and 14 mm. width each approximately.
•  Power motor min. 3.7 Kw./380V./3phase/50Hz.
•  Automatic and manual longitudinal travel min. 880 mm.
•  Automatic and manual vertical travel min. 400 mm.
•  Automatic and manual cross travel min. 250 mm.
•  Complete with automatic feed for all axis by gear.
•  Taper size of vertical spindle ISO40.
•  Taper size of horizontal spindle ISO 40.
•  Swiveling of working table at left/right min. 45 degrees.
•  Swiveling of spindle head at left/right min. 45 degrees.
•  Spindle speed gear type change min. 10 steps or variable speed type.
•  Minimum spindle speed not more than 60 rpm. and maximum spindle speed not less than 1,400 rpm.
•  Machine must be equipped with metric scale.
•  Coolant systems.
•  1 set of steel clamping kit (not less than 45 pieces).
•  Swiveling machine vise turn 360 degree, clamping width min. 200 mm.
•  1 set of dividing head (40:1) complete with tail-stock.
•  1 set of circular table (120:1) 250 mm diameter.
•  1 set of quick change holder NT40 or ISO40.
•  1 set of quick change multi-lock milling chuck Nt40.
•  1 set of straight collet chuck 22 mm. diameter complete with collet size 6,8,10,12,16 and 20.
•  1 set of quick change face mill arbor 25.4 mm. diameter NT40 or ISO40.
•  1 set of quick change drill chuck arbor NT40 or ISO40.
•  1 set of face mill diameter 80 mm. and inside diameter 25.4 mm.Can be hold 4 cutting tool not less than 4 pieces with spare carbide tip 10 pieces.
•  1 set of horizontal milling arbor ISO 40 ( O 25.4 mm.)
•  1 set of splash guard.
•  1 set of quick change boring system ISO40.
•  1 set of parallel steel.
•  1 set of leveling block.
•  1 set of machine lighting.
•  1 set of standard service tool.
•  Complete with 3 axis digital readout system and resolution 0.005 mm.
•  1 set of vibration support.
