STANDARD PENETROMETER WITH AUTOMATIC TIMER

Product Description

Standard Penetrometer With Automatic Timer

Biotek Engineers is manufacture, exporters & suppliers of Standard Penetrometer With Automatic Timer

General Descriptions And Specifications:

The apparatus is available in two versions, Hand operated and Electrically operated with automatic timer. The apparatus consist of a cast aluminum base with an iron stand on which moves an aluminum arm. A 6" dial is fixed on this arm and a brass chromium plated rod slide through the lower portion of the arm. A needle with weights is fitted to this rod. The dial is graduated from 0-400 in one tenth millimeter sub division. Supplied complete with adjustable needle holder, penetration needle, sample container, transfer dish and weight of 50 gm.

The Automatic model is supplied with automatic digital timer and electrical arrangement to carryout the test without need of stop watch and with great ease and accuracy, even by a layman.

Optional Accessories and parts

The following accessories and consumables are not part of the standard supply and are supplied at an extra cost
Constant Temperature water Bath
Enamel Tray
Glass Thermometer
Stop Watch Mechanical / Digital
Electric Hot Plate
Spare penetration needle
Spare Bitumen Container 55 mm x 35 mm
Spare Weight 50 gm
