Softening Point Apparatus

Product Description

Softening Point Apparatus

Biotek Engineers is manufacture, exporters & suppliers of: Softening Point Apparatus

General Description & Specifications

The apparatus consist of Glass beaker of heat resistant glass of internal dia 8.5 cm X 12 cm depth (approx.), Two steel balls each of 9.5mm dia. (Weighing 3.50 + 0.05gm). Two tapered brass moulds, Two ball guides, ring stand. Supplied with a heating unit designed to give temp. rise at 50C per minute as required under standard. The temperature is controlled with an energy regulator. In addition, there is an electrically operated stirrer mounted on a stand with chuck and glass rod or aluminum rod and for stirring the water in the water bath. Operation on 230 Volts. single phase, 50 Cycles, AC.

Optional Accessories

• The following accessories are not part of the standard supply and supplied at an extra cost.
• Thermometer 60 C.
• Thermometer 61C.
• Programmable Digital Temp. indicator cum controller
• Glycerin
• Brass plate for specimen preparation
• Cooling Cabinet
