Sieve Plate Distillation Column
Biotek Engineers is manufacture, exporters & suppliers of: Sieve Plate Distillation Column
Having extensive knowledge and rich understanding of the market, we are able to manufacture and export a premium range of Sieve Plate Distillation Column. Made and designed using quality stainless steel with seven sieve trays, these columns are used for demonstrating the principles of distillation in a sieve plate.
Features:
Ruggedness
Lightweight
Longer service life
Further Details:
The setup is designed to demonstrate principles of distillation in a Sieve Plate Column.
The column is made of Stainless Steel material with seven sieve trays. An electrically heated re-boiler is installed at the bottom of the column. The bottom product is collected in the tank. The vapors form the top of column are condensed in the shell and tube type condenser by circulating cooling water supplied by laboratory overhead tank. The condensate is divided into reflux & distillate and R/D Ratio can be varied. Reflux is fed back to the column and distillate is received in a receiving tank. The complete column is insulated for minimizing the heat loss. Instrumentation is done for pressure & temp. Measurement wherever is necessary.
EXPERIMENTS:
To study the Sieve Plate Distillation Column
FEATURES:
Stainless Steel tanks and wetted parts
Superb Painted structure
Simple to operate & maintain
Compact & stand alone set up
UTILITIES REQUIRED:
Water Supply 2 LPM at 5 m head
Drain
Electricity Supply: 1Phase, 220 V AC, 6.5 kW
Required Chemicals
Refractrometer for analysis
TECHNICAL DETAILS:
SIEVE PLATE DISTILLATION COLUMN
Distillation Column Material Stainless Steel Dia 100 mm
Packing Material Sieve plates seven nos.
Rota meter For cooling water flow rate measurement.
Re-boiler Made of Stainless Steel, provided with Pressure gauge (Bourdon type, 0-2kg/cm2) & Level Gauge. Safety valve & insulated with ceramic wool
Condenser Shell & Tube Type made of Stainless Steel.
Collection Tank Distillate & bottom product capacity 5 Ltrs. each
Heaters Nichrome wire heater
Piping PVC/SS
Temp. Sensors RTD PT-100 type
Control panel
Digital Temp. Controller: 0-199.9degC, For Steam Re boiler Digital Temp. Indicator: 0-199.9degC. with multi-channel switch On/off switch, Mains Indicator etc
Optional Utility Extra Refractrometer
