Shaking Machines Rotary

Product Description

Shaking Machines Rotary:

Biotek Engineers is manufacture,  exporters & suppliers of Shaking Machines Rotary

Shaking Machine Rotary (horizontal) : Continuous shaking of flasks from 100 to 500 ml capacity. Bench type table top model with platform with rubber discs/steel clamps mounted on ball-bearing crank-shafts to give an orbital motion to flasks within a diameter of 2". Motor is coupled with v-belt with a pitch pulley and mounted on heavy angle iron frame. Machine supplied with fixed or variable speed controlled by mechanical speed controller. To work on 220V AC 50Hz single phase.

Specifications:

Platform sizes      Holding Capacity     H.P. Motor
45 x 45 cms         25 flasks of 100 ml     0.25
45 x 45 cms         36 flasks of 50 ml     0.25
45 x 45 cms         16 flasks of 250 ml     0.25
55 x 55 cms         25 flasks of 250 ml     0.25
65 x 65 cms         36 flasks of 250 ml     0.5
100 x 100 cms         81 flasks of 250 ml     1
100 x 100 cms         81 flasks of 500 ml     1

Note : Other sizes and capacities can be fabricated on demand.
