RING AND BALL APPARATUS (MANUAL)

Product Description

RING AND BALL APPARATUS (MANUAL)

Biotek Engineers is manufacture, exporters & suppliers of: RING AND BALL APPARATUS (MANUAL)

This apparatus is used to determine softening point of bitumen. Ring and ball apparatus is used to determine softening point. It is that temperature at which a sample of bituminous material loaded by a 9.5mm dia steel ball drops at a distance of 25mm.

Salient Features

The apparatus consists of steel bracket with a sliding plate support.

The support has two holes of 10mm dia on which a Ring and Ball guide can be kept.

A central hole on this plate is for inserting thermometer. Supplied with a glass beaker approximate 8.5cm. I.D. 12cm high and a hand stirrer and 2 nos. 9.5mm dia steel balls.

Ring And Ball Apparatus  (Electrical) :

Same as above but supplied with a thermostatic hot plate. suitable for operation of 230 V A.C.

Accessories

Thermometer IP 60C range 2degC to 80degC,

Thermometer IP 61C range 30degC to 300degC x 5degC.

Electrical Stirrer with stand & blades to gently stir water in the beaker.

Suitable for operation on 230V AC
