Orifice And Free Jet Flow

Product Description

Orifice And Free Jet Flow  :

Biotek Engineers is manufacture, exporters & suppliers of Orifice And Free Jet Flow.

Orifice And Free Jet Flow  :

Important Features and Specifications:

Sharp Edged Orifice, Two Nos.,Cylindrical methacrylate tank, clear transparent, 300mm diameter, 500mm height, Supported on tripod legs with provision for leveling. Maximum constant head: 420mm. Max. Flow rate: 14lpm. Jet Trajectory Tracing Device with silkscreen printed scale, No. of  Jet trajectory probes: 8. Pitot tube, positioning unit and manometer to measure the actual head over the Orifice.

Following is the list of experiments that can be carried out using the Orifice and Free Jet Flow Apparatus:

• Determination of co-efficient of velocity for an Orifice.
• Determination of co-efficient of discharge for an Orifice.
• Study of the co-efficient of discharge of Orifice with flow under constant head and flow under varying head.
• Study of co-efficient of discharge at various values of head over the Orifice to study the influence of flow Reynolds number.
• Comparison of the measured trajectory of the jet with the trajectory calculated from simple theory.
• Study of trajectory of jet at various values of head over the Orifice.
• Comparison of results obtained for two different diameter orifices.
