MULTI-PUMP TEST RIG

  • Radial flow reaction turbine.
  • Designed to enable students to study the operation and performance characteristics of a typical single stage Francis turbine.
  • The unit has a sump tank and a centrifugal pump driven by electric motor to supply and re-circulate water.
  • The turbine is mounted with the axis horizontal on the top of the robust mobile frame.
  • Water enters the turbine casing through a variable area flow meter.
  • A hand operated valve should be provided at the inlet to control inlet head and flow rate.
  • After passing through the stationary guide vanes and runner, water should be discharged through tube to the sump tank.
  •  A ring mechanism should be provided to vary the position of inlet guide vanes.
  • The flow rate though the runner can be controlled by operating inlet guide vanes.
  • Transparent observation window provided to see operation of inlet guide vane mechanism.
  • Power generated in the turbine is absorbed by a disc brake dynamometer and the torque is measured using load cells.
  • Instrumentation and control panel should be included.
  • The complete unit should be manufactured from corrosion resistant materials.
  • List of Experiments to be achieved.
  • Study of construction of Francis Turbine
  • Determination constant head characteristics curve
  • Determination of constant speed characteristics curves
  • Determination of constant efficiency curves.
Features and Specifications:
  • Francis Turbine unit: 3.7Kw at 1250RPM.
  • Dynamometer.
  • Pressure gauge.
  • Flow meter, Venturimeter, Manometer.
  • AC motor: 3 or 15 H.P.
  • Valves, Pipes, Electric cables.
  • Sump tank.
  • Centrifugal pump to power the turbine.
  • Set of Weights.
  • Electrical supply, 3 phase, 380/415 V, 50 Hz.
  • Water supply and drainage.
