Motor Driven Disintegrator

Product Description

Motor Driven Disintegrator

Biotek Engineers is manufacture, exporters & suppliers of : Motor Driven Disintegrator

Motor Driven Disintegrator
Laboratory size, hammer type, with H.P. (Single phase) 220 volts, 50 C/S A.C. Consisting of four steel hammers fixed to a disc of 3” in dia 1” thick through which passes a shaft being revolved at 3000 R.P.M The hammers are enclosed in a C.l. Drum, the sides and upper surface of which are roughened. The inner surface is undulating.The lower part of drum is made of chrome plated brass and is detachable so that, SS sieves of different mesh size (a set of three sieves of coarse, medium and fine (Supplied with the instrument) can be easily placed. Hopper is made of die casted alluminium, Built on angle iron frame of size 24”x 14”x 2” high* 1/4 H.P. Or ½ H.P. Or 1 H.P (acc. To specification provided by customer)-Do- mounted on Iron base. Size 18”x 12” (small size).
