Mechanical Heat Pump Trainer

Biotek Engineers is manufacture, exporters & suppliers of: Mechanical Heat Pump Trainer

SPECIFICATIONS:

Compressor - Hermetically sealed compressor using R-12 refrigerant, having capacity 0.3 tons of refrigeration. Condensing pressure - max. 15 Kg/cm2 (Actual pressures will depend upon working conditions).

•     Condenser - Shell and coil type with continuous water flow arrangement.
•     Evaporator - Shell and coil type with continuous water flow arrangement.
•     Expansion Valve - Internally equalized thermostatic expansion valve.

Measurements -

• Rotameter for condenser & evaporator water flow rate measurement.
• Rotameter for liquid refrigerant flow measurement.
• Pressure gauges for condensing and evaporating pressure - 2 Nos.
• Thermometer for refrigeration cycle & water temp, measurement - 7
• Wattmeter for compressor input measurement.
• Ammeter for compressor current measurement.


Controls -

HP/LP cutout for compressor.
Overload protector for compressor.
Gate valve to control water flow rates.
Necessary switches and fuse.
A technical manual is accompanies the unit.

SERVICES REQUIRED:

Floor surface area - 2m, X 2m. X 1.5m. height.
220V., 15Amp., Single Phase Stabilized power supply.
