Logic Training Board on Counters & Shift Registers
Biotek Engineers is manufacture,exporters & suppliers of : Logic Training Board on Counters & Shift Registers
We are able to offer Logic Training Board on Counters & Shift Registers. The offered range is known for studying counters & shift registers and making the students familiar with design and practical aspects of all types of counters, shift registers and their applications in frequency measurements & computers. Possessing gates and flip-flops, the offered range is best suited for developing construct any type of counter, shift register and allied. Along with this, the offered range possesses decoder and seven segment display that aid in tracking the output of each circuit. This training board can conduct around 25 different experiments that cover altogether important aspects of computer, input and output devices.
Features:
The board consists of the following built-in parts:
- + 5 V D.C. at 1Amp, IC regulated power supply internally connected
- Five, J-K master slave flip-flops with preset and clear arrangement
- Six, 2-input NAND gates
- Four, 4-input NAND gates
- Three, 4-input AND-OR gates
- Two inverters (NOT gates)
- A 4-bit binary counter to demonstrate the basic principles of frequency measurement
- A square wave oscillator of frequency 10 Hz, 1 Khz and 10 KHz with coarse and fine variations, demon strata the basic principle of frequency division
- Completely programmable panel to make any type of counter or shift register
- Two pulser switches for clear and clock arrangement
- One mono pulser to give a 1 sec pulse
Objects:
Counters:
- 4-Stage binary ripple up-counter
- 4-Stage binary ripple down-counter
- 4-Stage binary ripple up-down counter
- Variable modules ripple counter by direct clearing
- 4-Stage decade ripple up-counter by direct clearing
- 4-Stage decade ripple down counter by direct clearing
Synchronous counters:
- 4-Stage binary synchronous up-counter with parallel carry
- 4-Stage binary synchronous down-counter with parallel carry
- 4-Stage binary synchronous up-counter with series carry
- 4-Stage binary synchronous down-counter with series carry
- 4-Stage binary synchronous up-down counter with parallel carry
- 4-Stage synchronous up-down counter with series carry
Series parallel counters:
- 3-Stage mod-5 series parallel counter
- 4-Stage mod-10 series parallel counter
Ring counter:
Johnson counters:
- 4-stage Johnson or shift counter
- Decade counter using 5-stage shift counter
Miscellaneous counters:
- Higher modules counter by combining two lower modules counter
- 2421 BCD counter
Shift registers:
To study the operation of:
- Serial to parallel converter
- Series-in-series output register
- Parallel to serial converter
- Parallel-in-parallel out register
- Right shift and left-shift register
Application of counters:
- To study the basic principle of frequency measurement
- To study the operation of frequency division by counter
- To study the principle of Random Access Memory by constructing its basic cell
