Product Description

Logic Probe 50MHz TTL/CMOS & Pulser

Biotek Engineers is manufacture,exporters & suppliers of : Logic Probe 50MHz TTL/CMOS & Pulser

Specifications:

  • Sync input impedance: 1MW
  • Pulse Rate: 0.5 / 400Hz
  • Pulse Width: 10mS
  • Output current: 100mA sink / Source
  • Square Wave Output Current: 5mA sink / source
  • Power Supply Range:5 - 15V DC
  • Power Supply Protection: 20V DC (30 seconds max.)
  • Sync Input Protection:120V DC (30 seconds max.)
  • Test Point Protection:35V DC (30 seconds max.)


Electrical (At 23±50C, 75% relative humidity maximum):

  • Maximum Input Signal Frequency:50MHz
  • Input Impedance:120K
  • Operating supply range: 4V DC Minimum,18V DC Maximum
  • TTL Logic "1" (Hi LED):3.0±0.25VW
  • Logic "0" (Lo LED):0.75±0.25V
  • CMOS : Logic "1" (Hi LED):60%Vcc±5%
  • Logic "0" (Lo LED):15%Vcc±5%
  • Minimum Detectable Pulse width:10 Nanoseconds
  • Maximum Signal Input Protection:±70V AC/DC (for 15 seconds)
  • Power supply protection.: ±20V DC
  • Pulse indicator Flash Time

Other Products in 'Logic Probe' category

Digital Colour Pattern Generator
