Product Description

LEAF AREA METER

Laboratory Leaf Area Meter

The Area Meter is designed for efficient, exacting measurements of both large and small objects. User-selectable area resolution of either 1 mm2 or 0.1 mm2 is available without having to change optics. This versatility provides the flexibility necessary for diverse project requirements.
  • Area, Length, Maximum Width, Average Width.
  • A single lens provides adjustable resolution of 0.1 or 1mm2.
  • High accuracy and repeatability, and fast, continuous operation for large quantities of samples with individual or cumulative area recorded.
  • Large (25 cm wide, 2.5 cm thick with 1 mm2 resolution) or small (<1 cm2 area when using 0.1 mm2 resolution) leaves or other objects, including needles.
  • Quiet belt system with adjustable press roller to flatten curled leaves.
  • Data are shown on the instrument LED display or on the computer screen using Windowsâ„¢ software to collect and store data via RS-232 or USB.
Plant Canopy Analyzer

Plant Canopy Analyzer uses a non-destructive method to easily and accurately measure Leaf Area Index (LAI). It consistently outperforms other methods such as Ceptometry and Hemispherical Photography in terms of flexibility, advanced features, accuracy, and ease of use.

LEAF AREA METER ( BTH-13LM ) :

  • Measuring Width:15cm max.
  • Measuring Length: 36cm.
  • Scanner: 670nm laser.
  • Resolution: 0.01cm2.
  • Accuracy: ±1% for samples >10cm².
  • Interface: USB 2.0.
  • Memory Size: 8,000 measurements.
  • Weight: 1,500.
  • Display: 16 characters x 2 lines LCD.
  • Scanning Speed: 200 mm/second.
  • Battery:7.2 volt rechargeable NiMH.
  • Battery Capacity: Over 250 scans per charge.



Other Products in 'Agricultural Laboratory Equipments' category

Seed Moisture Tester
