Lathe Tool Dynamometer

Lathe Tool Dynamometer

Product Details:

X

Product Description

Lathe Tool Dynamometer

Biotek Engineers is manufacture,exporters & suppliers of :Lathe Tool Dynamometer

Measure cutting forces on various machines like lathe, drill, milling machines. All three direction forces are measured simultaneously and displayed. Tool dynamometers are useful to study, analyse the optimum feed, speed and depth of cut on different materials. The dynamometers are also available in various capacities as per customer requirement.

SPECIFICATION:

 Model
UIL-15
 Capacity500 Kg in X,Y & Z direction
 Tool Size
20 mm square
 Dynamometer Mounting hole
25 mm dia Hole to mount sensor on tool post.
 Sensor Type
Strainguage based 350O bridge.
 Connection
9 pin D connector with shielded cable.3 meter length.
 Housing
Metal Enclosure with chrom plating.
 Display
3 independent for X,Y & Z force.3½ digit LED display.
 Resolution
1 kg for all the 3 components.
 Recorder o/pAnalog output for connect any recorder.or data logger provided.
 Zero Balancing
Corse and fine potentiometer on front panel.
 Power
230V 50 Hz
 Enclosure
Powder coated metal box.400(L)x300(W)x100H
 Accessories
20mm HSS tool bit- 1 No.
 Necessary cable
 Optional (Extra Cost) RS232 Interface to computer for datalogging with LCD isplay.
