Laminar Flow Table

Laminar Flow Table

Get a Price/Quote

Product Details:

Request to Call Back Send Inquiry
X

Product Description

LAMINAR FLOW TABLE
  • Designed to simulate ideal fluid flow and give clear visualisation of the flow patterns created using water as the working fluid.
  • This enables a comprehensive investigation into the principles of potential flow and allows modelling of appropriate physical systems.
  • Floor standing apparatus demonstrates ideal flow, and Hele Shaw principles and is able to accept student made models.
  • Working section and end tanks made of glass reinforced plastic.
  • Working section dimensions 606mm x 892mm. Actual viewing area 495mm x 755mm.
  • Lower glass plate incorporates 8 sinks/sources in cruciform pattern and viewing graticule.
  • A system of pipes, valves and manifolds enables any configuration of sinks and sources to be used.
  • Includes dye injection system and adjustable knife edge weir for rapid, accurate adjustment of table flow.
  • Comprehensive instruction manual with illustrations.
 Experiments:
  • Ideal flow around immersed bodies cylinder, aero foil, bluff body, Ideal flow in channels and at boundaries convergent channel, divergent channel, 90 degree bend, sudden contraction, sudden enlargement, replacement  of a streamline by a solid boundary, Ideal flow associated with sinks and sources formation of Rankine half body, formation of a Rankine oval, circular streamlines from a doublet, superposition of sinks and sources, Use of streamlines to analys two dimensional flow, Research - modeling two-dimensional systems.

Other Products in 'Building and Civil Engineering Equipments' category

Box Sextant
Send Inquiry
PIPE BENDING MACHINE
