Heat Transfer Through Composite Wall

Product Description

Heat Transfer Through Composite Wall

Biotek Engineers is manufacture, exporters & suppliers of: Heat Transfer Through Composite Wall

RANGE OF EXPERIMENTS TO BE CARRIED OUT :

To determine total thermal resistance & thermal conductivity of composite wall.
To plot temperature gradient along composite wall structure.
The experiments can be conducted at various values of input & calculation can be made accordingly.
To plot Heat flux Vs thermal conductivity in composite structure.

EXPERIMENTAL SETUP :
1. Heater Assembly.
2. Test specimen MS 2 Nos. Bakelite 2 Nos. Wood 2 Nos.
3. Assembly Mounting frame.
4. Clamp Plates 2 Nos.
5. Set of thermocouples.

CONTROL PANEL :
1. 12 Channel Digital Temperature Indicator
2. Dimmerstat : 0 - 2 A.
3. Main's On/Off Switch.
4. Voltmeter : 0 - 250 V.
5. Ammeter : 0 - 3 A.

SPACE REQUIRED :
1.5 m.(L)x 1.0 m(W) table top.

Service Required :
230 v Ac Supply 50 Hz
WEIGHT :  70 Kg approx.
