Fluidisation And Fluid Bed Heat Transfer Unit :

Biotek Engineers is manufacture, exporters & suppliers of Fluidisation And Fluid Bed Heat Transfer Unit.

Description :

This is a dryer in which moisture removal takes place by fluidization of solids particles by hot air. The set-up fitted with a specially designed, vertical Glass Column. The lower portion of the column is filled with fluidizing material. The material is supported on the screen mesh held between two flanges. Air from a compressor is heated in the heater box and passed through the column. Flow control and by-pass valve are fitted to regulate the airflow. At the top outlet of column a cyclone is provided to collect any solid particles taken out by the air stream.

Experimentation :
  • To study the fluidized bed drying.
  • To plot the drying curve under fluidized bed condition.

Utilities Required :
  • Electricity Supply : 1 Phase, 220 V AC, 3 kW.
  • Granular and free flowing solid of size 1 to 2 mm.

Technical Details :

  • Column : Material Borosilicate Glass Dia. 80 mm. Total Length 500mm.
  • Cyclone Separator : Material Stainless Steel, Compatible Capacity with collector.
  • Air Circulation : By forced draft fan, Arrangement is done vary the air flow rate.
  • Heating Chamber : Compatible capacity
  • Heater : Nichrome wire heater
  • Temperature Sensors : RTD PT-100 type.
  • Control panel comprises of :
  • Digital Temp. Controller : 0 199.9°C (For Hot Air) Standard make on/off switch, Mains Indicator etc.
  • Instruction Manual : An ENGLISH instruction manual will be provided along with the Apparatus
  • The whole set-up is well designed and arranged in a good quality painted structure.

Other Products in 'Chemical Engineering Laboratory Equipments' category

Rising Film Evaporator
