Flow Meter Demonstration

Product Description

FLOW METER DEMONSTRATION

• Bench top open channel unit designed to conduct experiments related to open channel flows and to visualize stream line patterns over or around various objects.
• The system is consist of a clear acrylic flow channel having large width-to -depth ratio.
• Overshot and undershot weirs should be provided at the inlet and exit of the channel section.
• The channel section should have a bell mouth entry to reduce flow disturbances.
• The water flow rate can be varied using a membrane type flow control valve fixed at the exit of the flow channel.
• Water flow rate and flow velocity should be measured by the volumetric measuring tank (of the hydraulic bench).
• Water should be supplied from the supply tank consisting of glass beads to reduce flow disturbances.
• Flow patterns should be visualized using dye injection through need levalves.
• Dye injection rate can be controlled and adjusted to improve the quality of flow patterns.

Experiments:

• Study of open channel flows
• Study of flow over weirs – over shot and under shot weirs, broad and
• narrow crested weirs.
• Familiarization with water flow visualization technique.
• Demonstration of laminar and turbulent flow.
• Study of streamline patterns around cylinders at different Reynolds numbers.
• Study of flow pattern around hump, disc, cuboid etc.
• Study of vortex shedding from cylinders and bluff bodies.
• Comparison of observed streamline patterns with theory.

Specifications:

• Flow visualization channel with bell mouth entry, 650mm length, 20mm width and 140mm height, transparent, made of clear acrylic.
• Supply tank with glass beads, 20 liters capacity.
• Dye injection system, 0.5 liters reservoir capacity, 5 dye injection needles with needle valves at exit.
• Depth gauge. 0 – 150mm range.
• Model fixture.
• Models: over shot weir, under shot weir, broad crested weir, sharp crested weir, hump, small cylinder, large cylinder.
• symmetrical airfoil, symmetrical airfoil with flap, un-symmetrical airfoil, wing, disc and cuboid.
• Computer based learning software.

• Electrical Supply, 240 V, single-phase, 50 Hz.
