Flow Channel With Models  :

Biotek Engineers is manufacture, exporters & suppliers of Flow Channel With Models.

Flow Channel With Models :

Specifications :
Open flow channel made of clear acrylic plastic,
20mm width, 160mm depth, and 625mm length.
Dye reservoir, capacity: 0.5 liters Dye injection needles, 5 Nos.

Models, 8 Nos.

(a) broad crested weir

(b) sharp crested weir

(c) symmetrical aerofoil

(d) non-symmetrical aerofoil

(e) cylinder, 15mm diameter

(f) cylinder, 30mm diameter

(g) ship model and

(h) hump

Experiments :

• Study of basic open channel flows with variable depth of flow.
• Calculation of Froude number and similarity of flows.
• Study of uniform flow, gradually varied flow and rapidly
• varied flow and Froude number correlations.
• Study of flow over different types of weirs – undershoot and  over shoot weirs, broad and sharp crested weirs.
• Study of flow under a sluice gate.
• Visualization of streamline patterns around aerofoil, cylinder, ship model, hump etc.
