Extractor Frame

Product Description

Extractor Frame

Biotek Engineers is manufacture, exporters & suppliers of: Extractor Frame

Extractor Frame for 38mm hand with mould

Extractor Frame Hydraulic

This extractor Frame is used for taking ut soil samples compacted or undisturbed, from 100 mm dia and 150 mm dia cylinders such as core cutters, Proctor moulds, C.B.R. moulds etc.
Salient Features Specifications : It consists of a 5 Tone capacity hand operated, hydraulic jack mounted on a suitable frame. Two plungers, one for 100 mm dia and the other of 150 mm dia moulds are supplied. One thrust plate for 150 mm dia and one for 100 mm dia specimens are also supplied. Height of thrust plate is adjustable.
Accessories : Set of Plungers adaptors and thrust plates for 38 mm, 50 mm and 75 mm dia specimen.
