Electronic Stimulator

Product Description

Electronic Stimulator

Biotek Engineeers is manufacture, exporters & suppliers of : Electronic Stimulator

Electronic Stimulator
It is available in four models.
a) Student Stimulators  Transistorized : Output 0-25 DC in two steps, duration 5 or 1.5 ms frequency 5 to 100 c/s in 11 steps, models single repetitive or an external trigger, for 220 V 50 HZ.
b) Student Electronic Latest Design :Frequency continuously variable from 0.1 Hz to 100 Hz. In 3 decades of 0.1 to 1,1 to 10 and 10 to 100 selectable through push- button controls and  one continuously variable control.
Output Voltage continuously variable from 0 to 30 V in two steps of 1 to 3 and 1 to 30, selectable through a switch.
Fixed pulse duration 1 m sec,
Single & external trig. Single pulse facility.
Sensitive speaker to give audible indication or each output.
High stability new circuitry minimizes external interference.
c) Stimulator General Purpose :  Provides rectangular pulse of controlled amplitude 0.1- 100 V, Frequency 0.1-1000 Hertz & width 0.01  to 100 m see. All solid state latest model.
d) Research Stimulator with R.F. Isolation Unit : Provides rectangular pulse of controlled polarity, Amplitude 1.5 m V to 150 V; Frequency 0.1 to 10 KCS. Delay 10 micro sec. to 1 sec. & width 10 micro sec. to 1 sec. All solid state.
