Product Description
ELECTRICAL POWER ENGINEERING
Power engineering trainer as follows:
- Allows easy and safe wiring due to use of 4mm sturdy Shrouded banana patch cords and shrouded socket arrangements for high voltage circuits
- Each panel has ABS molded plastic sturdy enclosure, and colorful screw-less overlays showing circuits diagrams &its connection tag numbers for easy understanding and connection Set of Instructor Guide & Student Workbook.
Input 3 phase DOL Starter panel
- 4 pole MCB of 415 V/2A.
- DOL 9A Contactor with 230V / 50 Hz / 11VA COIL.
- Bimetallic thermal O/L relay with range 1.4A - 2.3A.
Resistor Load
- AC Resistors = 10K/5K/3.5K/2.5K/2K/1.5K/off 200WX3 phases/ 6 taps
- DC Resistors = 750E/600E/300E/212E/162E/ 125E/off 112E/100E/400W / 6 taps off
LC Load panel
- Inductive load
- Capacitive load
1 phase Motor, Alternator & Sync. Motor Panel
- 1 phase MCBs of 4A/1.6A - 2nos.
- 2 no. 2P2W selector switches to run as 1 phase alternator then as synchronous motor.
- 8A pushbutton switch to simulate as centrifugal switch.
Integrated AC 1 phase measurement panel
- Consist of 96x96mm Digital meters one each for 1 phase Measures V,I,PF (0.2 lag unity 0.2 lead), Hz. Hence separate analog wattmeters (3phase,1phase) are not needed.
- Current specs for 1 phase meter =1A/5A
Variable voltage & current injector panel
- Consist of 1 phase dimmer 230VAC/1A
- Short circuit transformer with primary 230VAC/1A, secondary 1V/ 20A.
Integrated AC 3 phase measurement panel
- Consist of 96 x 96mm Digital meters for 3 phase. Measures V, I, PF (0.2 lag unity 0.2 lead), Hz. Transmission line panel
- Simulated model for short transmission line using R (10 ohm) & L (45 mH) components.
- Simulated model for medium length transmission line for II model.
- Simulated model for medium length transmission line for T model.
Over current and elapsed time measurement Panel
- Consists of AC ammeter of 20A.
- Elapsed time counter range 999.001 msec, resolution 1msec.
Phase sequence indicator and study Expt. Panel
- Study 3 phase 440V Electric utility supply.
- Determination of over voltage, under voltage, single phasing and reverse phasing / Displays OV, UV, SP, RP on digital display.
- 9 V Battery / +12V Supply operated.
