Drafting Plotter

DRAFTING PLOTTER

• Plotter: Monochrome / Colour Wide format Inkjet AO Print.
• Technology: FINE (Photolithography Inkjet Nozzle Engineering).
• Ink Supply Method: Tubing system (independent ink tanks).
• Nozzle Recovery System: Non-firing Nozzle Detection and Compensation.
• Printer Controller: L-COA Controller.
• Droplet Size: 4 Picoliter.
• Nozzle Pitch.
• (Head Resolution): 1200dpi x Two Rows.
• Media Cutter: Automatic horizontal cutting (Rotary cutter), independent unit.
• Front-loading Manual Feed: 0.07 - 0.8mm.
• Roll Feed: 0.07 - 0.8mm.
• Media Core Sizes: Internal diameter of roll core.
• Maximum Roll Outer Diameter: 150mm.
• Front-loading Manual Feed: 0.07 - 0.8mm.
• Printer language: GARO (Graphic Arts language with Raster Operations), HP- GL/2, HP RTL.
• Operating Systems: Windows 2000 / XP / Windows Vista Macintosh OS 9 / 10 (PowerPC or Intel).
• Standard (Built-in): USB 2.0 Hi-Speed, 10 / 100Base-T / TX.
• Power Source: AC 200-240V, 50-60 Hz.
• Roll Feed: 0.07 - 0.8mm.
• Media Core Sizes: Internal diameter of roll core.
• Maximum Roll Outer Diameter: 150mm.
• Front-loading Manual Feed: 0.07 - 0.8mm.
• Printer language: GARO (Graphic Arts language with Raster Operations), HP- GL/2, HP RTL.
• Printer language: GARO (Graphic Arts language with Raster Operations), HP- GL/2, HP RTL.
• Operating Systems: Windows 2000 / XP / Windows Vista Macintosh OS 9 / 10 (PowerPC or Intel).
• Standard (Built-in) : USB 2.0 Hi-Speed, 10 / 100Base-T / TX.
• Power Source: AC 200-240V, 50-60 Hz.
• Standard sheet medium size Width along Platen.
• A (8 l/2 x 11 inches) No.
• A4 (210 x 297 mm).
• B (11 x 17 inches) Yes.
• A3 (297 x 420 mm).
• C (17 x 22 inches) No
• A2 (420 x 594 mm)
• D (22 x 34 inches) Yes.
• A1(594 X 841 mm).
• E (34 x 44 inches)A0 (841 x 1189 mm) Yes.
