Determination of CD,CV & CC Orifices

Product Description

Determination of CD,CV & CC Orifices

Biotek Engineers is manufacture, exporters & suppliers of: Determination of CD,CV & CC Orifices

Our company is instrumental in the manufacturing and trading of premium quality Study of Pipe Fittings, Sudden Enlargement & Contraction App
These products are manufactured under strict supervision in accordance with the industry set norms and parameters. Offered apparatus is a self-contained water re-circulating unit, provided with a sump tank and a centrifugal pump etc. Flow control valve and by-pass valve are fitted in water line to conduct the experiment on different flow rates.

Experiments:

    To determine loss of head in the fittings at various water flow rates
    To measure the loss coefficient for the pipe fittings

Utilities Required:

    Electric supply 0.5 kW, 220V AC, Single Phase
    Water supply Tap water connection ” BSP Distilled water @ 60 liters (optional)
    Floor Area with Drain facility

Technical Specifications:

    Sudden Enlargement: From 15 mm to 25 mm
    Sudden Contraction: From 25 mm to 15 mm
    Bend: 1/2 “
    Elbow: 1/2 “
    Ball valve: 1/2 “
    Gate valve: 1/2 “
    Instruction Manual: An english instruction manual will be provided along with the Apparatus
    The whole set-up is well designed and arranged in a good quality painted structure
