Core Cutting/ Core Drilling Machine( Motorized)

Product Description

Core Cutting/ Core Drilling Machine( Motorized)

Biotek Engineers is manufacture, exporters & suppliers of: Core Cutting/ Core Drilling Machine( Motorized)

The machine is suitable for care samples of size upto 150mm diameter with the help of thin walled diamond bits which are at extra cost. The machine has sturdy base with pillar support in which rack & pinion is provided for adjustment in height and penetration assembly. The leveling screws are at the base. For gripping the damply in positions suitable grips are provided. A suitable electric motor, standard make is fitted in the machine with cooling arrangement with water. The base frame is also fitted with wheels for ease of transportation.

Salient Features:-

    Dimension approx. are as under :
    Height : 1300mm
    Base : 600 x 1200mm
    Head travel on rack : 350mm
    Drill Speeds : 900 RPM for soft samples and 350RPM for hard samples.
    Water Swivel : Built in the machines.
    Suitable for 230 volts AC, single phase
    Accessories : 1. Thin wall diamond bits 2. Core Barrel.
