Compression Testing Machine

Product Description

Unconfined Compression Tester Proving Ring Type (Motorised)

Biotek Engineers is manufactures,exporter & suppliers Unconfined Compression Tester Proving Ring Type (Motorised)

Unconfined Compression Tester Proving Ring Type (Motorised)

This is with the added advantage of a motorised drive permitting a choice of three constant rates of stain.

SPECIFICATION :

Comprises a screw operated load frame, cap.5000kg with a gear box and motor drive giving 1.25, 1.5, 2.5mm/min. Rates of strain, a pair of cone seating, adaptor for proving ring, and stain dial gauge bracket. Supplied with one pair of male/female coning tools for 38mm dia samples but without ring and dial gauge. Suitable for operation on 230 V, Single Phase A.C. Supply.

ACCESSORIES :

Coning tools in pairs (Male & Female) for samples having diameter 38mm, 50mm, 75mm
