Comparison of Pumps

Product Description

Comparison of Pumps

Biotek Engineers is manufacture, exporters & suppliers of: Comparison of Pumps

[1] Experiments relating to key issues in pump engineering

[2] Comparison of various pump types: Centrifugal pump, piston pump, side-channel pump

[3] Operation of centrifugal pumps in parallel or series

[4]Three-phase AC motors for centrifugal pumps and additional motor with variable speed by frequency converter

Technical Data:

Centrifugal pump 2x- max. flow rate (Q): 300L/min- max. head (H): 16,9m - nominal speed: 2900min-1Three-phase AC motor 2x, for centrifugal pump- power output: 750W- speed range: 750...3000min-1Side-channel pump, self-priming, one-stage- Q: 83,3L/min, H: 50m - nominal speed: 1450min-1Three-phase AC motor for side-channel pump- power output: 1,1kW- speed: 1500min-1Piston pump- Q: 17L/min, H: 60m - nominal speed: 405min-1Three-phase AC motor for piston pump- power output: 0,55kW- speed: 1500min-1Three-phase AC motor, additional motor, reversible- power output: 0,75kW- speed range: 750...3000min-1Measuring ranges- flow rate: 0...500L/min- intake pressure: -1...1,5bar- delivery pressure: 0...10bar- torque: 0...15Nm- speed: 0...3000min-1- pump electrical power consumption: 0...2000W
