CNC Lathe Machine with Cabinet And PC

Product Description

CNC Lathe Machine with Cabinet & PC

Biotek Engineers is manufacture, exporters & suppliers of : CNC Lathe Machine with Cabinet & PC

General specification:

•     Max. distance between centers: 360 mm
•     Swing over bed: 100 mm
•     Swing over apron: 60 mm
•     The width of bed: 100 mm
•     The speed of the spindle: 100-2250 r/min
•     The max. speed of moving (X,Z): 2000 mm/min
•     The speed of feeding (X,Z): 500 mm/min
•     Max. travel - Z axis: 250 mm
•     Max. travel - X axis: 150 mm
•     Motor of X axis: 1.35 Nm
•     Motor of Z axis: 1.35 Nm
•     Tool position: 4
•     Angle of the tool post: 360°
•     Travel of tailstock: 50 mm
•     Position accuracy: 0.015 mm
•     Repeatability accuracy: 0.01 mm
•     Tool post return orientation precision: 0.005 mm
•     Main motor power: 600W
