CBR Load Frame Three Speed Motorised

Product Description

C.B.R. Load Frame Three Speed Motorised:

Biotek Engineers is manufacture, exporters & suplliers of: C.B.R. Load Frame Three Speed Motorised

C.B.R. Load Frame Three Speed Motorised

Load Frames

Our Load Frames are used to apply load on the test specimen. The capacity and speed depends on the requirement of a particular test and these are used in C.B.R. triaxial, unconfined compression test. Further, these are Ideal for using mobile laboratory.Load Frame, Motorised, 30 speeds (50 kN) cap.Two Pillar type, Detachable frame, Enclosed motor and gear system, Jewel lamps indicating direction of motion, Speed chart.Consists of a cabinet which housed the gear system & motor with sturdy angle iron frame.The loading is done through the bottom loading platen, which is carried on a lead screw which advances upwards.The top load bracket which slides over two upright pillars, can be positioned at any desired height and locked. It caries a screw adaptor for standard Proving ring. Rate of strains : 30, ( 6 mm/min to 0.00048 mm/min by interchanging the drive and driven gears, another set of 24 rates of strain can be obtained. 220V, 1 Ph, 50 cycles, AC supply.The Loading part of the unit is detachable from the main unit for ease of transport and to avoid damage to the tension rods.
