CAM AND FOLLOWER APPARATUS

Product Description

• To determine follower displacement against angular rotation of acam; hence derive velocity and acceleration diagrams and determine the maximum acceleration of the follower; for a variety of cams and followers.
• Bench mounted unit consisting of main spindle for each cam and a dial gauge. Each cam is mounted on a central shaft and is free to rotate about this shaft. The cams are rotated by hand.
• The angular position of the cam is shown on a protractor and a pointer, It allows the cams position through rotation to be recorded.
• A set of cams are supplied as standard along with a set of followers which run on the perimeter of each cam.
• Each cam can be easily changed and the angular and dial gauge readings are clear.
