Bitumen pentrometer electronic automatic

Product Description

Bitumen pentrometer electronic automatic : -

Biotek Engineers is manufactures,exporter & suppliers Bitumen pentrometer electronic automatic.

Bitumen pentrometer electronic automatic

A compact instrument using the latest technologies and programmation tools. The apparatus is supplied complete with outfit for penetration of bituminous materials including needle, holder, 50 g weight and 10 containers.
The test should be performed placing the penetration cup in thermostatically controlled water, using the suitable device as the 81-B0102/C Digital circulation water bath with conditioning vessel.

Technical Specification

Built-in user friendly software
Full automatic approach on conductive products and hard bitumen
Four programmable reference positions for the cone holder assembly
Stepper motor for penetration depth as low as 0.01 mm
Programmable penetration time between 0 and 999 min
Temperature measurement: -10 to 150°C
Range: 0 to 75 mm
Results: in 1/10 mm on full range
Displayed resolution: in 1/100 mm
Position recall for routine tests can be set
Optoelectronic detection of depth penetration
Optional automatic level detection for bitumen
Three last tests displayed with calculated average
Connection: 2 USB ports – 1 for printer or keyboard and 1 for PC
Adjustable led lamp and magnifying glass
Standard outfit
Supplied complete with outfit for penetration of bituminous materials (needle, holder, 50 g weight, 10 containers), magnifying lens, low voltage illuminator, centring guide, etc.
Overall dimensions (wxdxh): 720x250x330 mm
Weight approx.: 16 kg
