Bernoulli’s Theorem Demonstration

Product Description

Bernoulli’s Theorem Demonstration

Biotek Engineers is manufacture, exporters & suppliers of: Bernoulli’s Theorem Demonstration

Features

This equipment enables to study the Bernoulli’s theorem through the use of a classical venture tube
Equipped with 6 static tapping points and a pilot tube for the measurement of dynamic pressure along the duct
The tapping points and pilot tube are connected with a seven tubes differential pressure gauge
The water flow rate is controlled by two valves placed at the inlet & outlet of the Venturi tube

Specifications

304 stainless steel structure
7 tubes pressure gauge, range 0 ~ 500 mm
Diameter of venture tube : 20 mm
Venturi tube throat diameter : 10 mm
Upstream taper : 14º
Downstream taper : 21º
Dimension : 650 x 400 x 850 mm

Training Program

Demonstration of Bernoulli’s theorem and of its limitations
Direct measurement of the static and dynamic pressure distribution along a Venturi tube
Determining the discharge coefficient of the Venturi tube
