8085 MICROPROCESSOR TRAINER

8085 MICROPROCESSOR TRAINER

•  CPU : 8085 Microprocessor @6.144 MHz
•  MEMORY: Total space ON BOARD is 48KB,Comprising of 16KB monitor EPROMS and 32KB RAM. Battery backup for RAM. No expansion required.
•  PERIPHERALS: 8279 for controlling 24 feather keys (including 6 digit seven segment display).
•  1 Timer/counter with three independently programmable counters.
•  Two 8255 for controlling 48 I/O lines and same are brought out to FRC 50 pin connector.
•  8251 for RS 232 C serial communication and firmware for UP/DOWN facility for IBM PC/XT/AT computer.
•  Built-in cassette interface.
•  Built-in Speaker interface.
•  Built-in EPROM programmer for 27128 operating at 12.5V.
•  INTERFACING : All buffered & demultiplexed TTL compatible signals brought on a 50 pin FRC connector including address and SIGNALS data control lines brought out at another 50 pin FRC connector. Several experimental interface modules can be connected to this trainer. They are ADC, DAC, Stepper motor, 8- bit switch input, 8-bit LED output, Relay interface module, etc. and many more are available.
