8 Directional Vertical Milling

Product Description

8 Directional Vertical Milling

Biotek Engineers is manufacture, exporters & suppliers of : 8 Directional Vertical Milling

It is prepared by making use of the qualitative and non-corrosive material. Also, it is very good at functioning level with higher efficiency.

Specifications:

    Max clearance, table to spindle: 229 mm
    Throat: Adjustable
    Travel:

a) “X” Axis: 229 mm,

b) “Y” Axis: 178 mm

c) “Z” Axis: 137 mm

    Hole through spindle: 10 mm
    Spindle nose thread: 3/4-16 T.P.I.
    Spindle taper: #1 Morse
    Table size: 70 x 330 mm
    Hold down provision: 2 “T” Slots
    Motor: 90 Volt DC with electronic speed control automatically converts any input from 100 VAC to 240VAC, 50 or 60 Hz
    Spindle speed range: 70-2800 RPM continuously variable by electronic speed control
